제품 상세설명







TH815      1x15" Two-Way Full Range Passive/Bi-amp Speaker       TH815 is a two-way full range speaker driven by bi-amp mode or switchable passive mode. The high quality compression driver with 75mm neodymium diaphragm features low distortion. Innovative deep dome structure design is greatly strengthening its stiffness and reducing distortion. Smooth frequency response curves shows thoroughly its convincing performance and reliability. Rotatable horn dispersion 80°(H)x50°(V) and trapezoid form enclosure make it well-suited in many different applications.   APPLICATIONS          Main speaker for auditorium, conference, theater, multipurpose. Main/fill in disco and club. Portable main, stage monitoring and LR fill in FOH.       SPECIFICATIONS

Frequency Response  50Hz-16kHz(±3dB) 40Hz-18kHz(-10dB) Sensitivity(1W/1m) HF:107dB LF:99dB Nominal impedance 8ohm Power Rated (AES) HF:75W LF:450W Dispersion(HxV) 80°x50°Rotatable Crossover  1.6kHz LF 15"/75mm voice coil/450W HF Titanium diaphragm neodymium magnet compression driver/75mm voice coil/75W  SPL  HF:126dB continuous , 132dB peak LF:126dB continuous , 132dB peak Connector 2NEUTRIK NL4MP Passive: 1 1-, Bi-amp:(HF)2 2-/(LF)1 1- Bi-amp  1 1- Passive (HF)2 2-(LF)1 1- Fittings M10x8 Dimension (WxDxH) 466mmx392mmx727mm Weight 28kg Driven mode Passive/Bi-amp Recommended AMP Passive: MA8200/R809   Bi-amp: (HF)MA3200/R803   (LF)MA8200/R809



스펙

제품사진

사용자평가

• th-815 사용기 2011-08-10 전광진

  디자인 : 성능 : 가성비 :
  요크빌 yx15를 사용하면서 저음에서는 아쉬운데로 들을만 했는데 중,고음에서 부족함을 느끼던차에 뮤플 최팀장님으로부터 권유로 LAX TH 815를 과감하게 선택하게 되었는데 가격대비 음질의 섬세한면에서 역시 잘선택했다는 생각합니다

리뷰

질문과 답변
