TH835
1x15" Three-Way Full Range Speaker



TH835 is a three-way 15" coaxial full range horn speaker.
The rotatable combination of HF-MF drivers unit delivers fidelity and precise directivity.
Another feature of the cabinet is its flexible coverage, and also with different install options.15" woofer
component is loaded behind the MF in a more compact enclosure to create much higher SPL. TH835 isoperated in combination with an external active crossover or a hi-cut filter.

APPLICATIONS


Main speaker for auditorium, conference hall, theater, stadium, multipurpose.
Main/fill in disco and club.
Mid/small scale portable event, shows, etc.


SPECIFICATIONS


Frequency Response  80Hz-16kHz(±3dB)
60Hz-18kHz(-10dB)
Sensitivity(1W/1m) HF: 110dB MF:108dB LF:108dB
Nominal impedance 8ohm
Power Rated (AES) HF: 75W MF: 200W LF:500W
Dispersion(HxV) 60°x40°Rotatable
Crossover  1.5kHZ/350Hz
LF 15"/100mm voice coil/500W
HF Titanium diaphragm neodymium magnet compression driver/75mm voice coil/75W
SPL  HF: 129 dB continuous , 135 dB peak
MF: 131 dB continuous , 137 dB peak
LF: 135 dB continuous , 141dB peak
Connector NEUTRIK NL8MP x2
HF: 1 1-MF:2 2-LF:3 3-
Enclosure  Horn Loaded
Fittings 3xMounting ring
Dimension (WXDXH) 557mm x 780mm x 1007mm
Weight 72kg
Driven mode Tri-amp
Recommended AMP HF:MA5200/R805
MF:MA7200/R807
LF:MA8200/R811

스펙

Frequency Response  80Hz-16kHz(±3dB)
60Hz-18kHz(-10dB)
Sensitivity(1W/1m) HF: 110dB MF:108dB LF:108dB
Nominal impedance 8ohm
Power Rated (AES) HF: 75W MF: 200W LF:500W
Dispersion(HxV) 60°x40°Rotatable
Crossover  1.5kHZ/350Hz
LF 15"/100mm voice coil/500W
HF Titanium diaphragm neodymium magnet compression driver/75mm voice coil/75W
SPL  HF: 129 dB continuous , 135 dB peak
MF: 131 dB continuous , 137 dB peak
LF: 135 dB continuous , 141dB peak
Connector NEUTRIK NL8MP x2
HF: 1 1-MF:2 2-LF:3 3-
Enclosure  Horn Loaded
Fittings 3xMounting ring
Dimension (WXDXH) 557mm x 780mm x 1007mm
Weight 72kg
Driven mode Tri-amp
Recommended AMP HF:MA5200/R805
MF:MA7200/R807
LF:MA8200/R811
