JRX215

JBL
제품코드 : 9262

가격

도매 할인가격 :
가입안내
뮤플 할인가격 :
할인가격 상담 :
할인가격상담 이란?

옵션 & 수량 & 장바구니

수량 :

소비자 가격 :

장바구니담기

관심상품담기

구매정보

제품상태 :

판매중

무이자 할부:

무료배송 :

10만원 이상 구매 시 무료
음향기기 > 음향 > 스피커 > 종류 > 패시브 스피커
음향기기 > 음향 > 스피커 > 용도 > 일반용

제품사진

이 제품의 연관제품

뮤플의 한 마디

“”

제품 상세설명

Two-Way Sound Reinforcement Loudspeaker System
This trapezoidal, 15" speaker system is at home in live sound, dance music and speech reinforcement.


FEATURES
∧
  • JBL 15 in low frequency driver with a 64 mm (2.5 in) diameter edgewound ribbon voice coil which provides more cross-sectional wire area in the voice coil gap than round wire designs, for greater efficiency and power handling.
  • JBL 2414H-C 25 mm (1 in ) polymer diaphragm compression driver improves high frequency performance as well as system reliability.
  • The advanced network topology crossover design shapes the frequency response to deliver coherent summation in the crossover region.
  • High-voltage capacitors and inductors with massive cores and heavy gauge wire enable the crossover network to handle high power without saturating.
  • Progressive Transition™ high frequency waveguide provides superior coverage control, reduced distortion, and smoother frequency response.
  • The rugged, acoustically superior enclosure is constructed from 19 mm (.75 in ) MDF (Medium Density Fiberboard) using advanced adhesives and mechanical fastener technology for extreme durability and improved low-frequency performance.
  • SonicGuard™ protects the high frequency driver from excess power without interrupting the performance.
  • Non-resonant, all-steel handles are used.
  • Attractive 18-gauge perforated, steel grille protects components from damage.
  • Dual-angle pole-mount socket allows the speakers to tilt 10° for more uniform audience coverage.

SPECIFICATIONS
^
Power Rating 250 W / 1000W
Frequency Range (-10 dB) 41 Hz - 18 kHz
Frequency Response (±3 dB) 59 Hz - 13 kHz
Sensitivity (@1m) 99 dB SPL (1w/1m)
Nominal Impedance 8 ohms
Recommended Amplifier Power 250 W to 500 W into 8 ohms
Maximum SPL 129 dB
Nominal Dispersion 90º x 50º
Crossover Frequency 2.2 kHz
Dimensions
(H x W x D)		 699 mm x 460 mm x 432 mm
(27.5 in x 18.1 in x 17 in)
Weight 27.4 kg (60.5 lb)
High Frequency Driver JBL 2414H-C , 1" exit compression driver mounted on Progressive Transition™ Waveguide
Low Frequency Driver JBL M115-8A
Input Connectors Neutrik® Speakon® NL-4 (x1); .25in TS phone jack (x1); parallel

스펙

PECIFICATIONS
^
Power Rating 250 W / 1000W
Frequency Range (-10 dB) 41 Hz - 18 kHz
Frequency Response (±3 dB) 59 Hz - 13 kHz
Sensitivity (@1m) 99 dB SPL (1w/1m)
Nominal Impedance 8 ohms
Recommended Amplifier Power 250 W to 500 W into 8 ohms
Maximum SPL 129 dB
Nominal Dispersion 90º x 50º
Crossover Frequency 2.2 kHz
Dimensions
(H x W x D)		 699 mm x 460 mm x 432 mm
(27.5 in x 18.1 in x 17 in)
Weight 27.4 kg (60.5 lb)
High Frequency Driver JBL 2414H-C , 1" exit compression driver mounted on Progressive Transition™ Waveguide
Low Frequency Driver JBL M115-8A
Input Connectors Neutrik® Speakon® NL-4 (x1); .25in TS phone jack (x1); parallel
