ZED 24

Allen&Heath
제품코드 : 6354

가격

할인 전 가격 :
₩1,281,000
도매 할인가격 :
가입안내
뮤플 할인가격 :
할인가격 상담 :
할인가격상담 이란?

옵션 & 수량 & 장바구니

수량 :

상담 할인금액 :

가격상담을 받기 전 입니다

최종 구매가격 :

장바구니담기

관심상품담기

구매정보

제품상태 :

판매중

무이자 할부:

구매 혜택 :

640W 증정

무료배송 :

10만원 이상 구매 시 무료
음향기기 > 음향 > 믹서 > 종류 > 아날로그 믹서

제품사진

이 제품의 다른 시리즈 제품

뮤플의 한 마디

“”

제품 상세설명

  • 6 mono channels
  • Neutrik mic XLR
  • Neutrik 1/4 inch jacks
  • Channel insert
  • Super wide gain ‘DuoPre’ mic line input
  • 3 band EQ with MusiQ
  • 4 auxes
  • Illuminated mute
  • Sound image pan
  • Illuminated PFL & peak warning indicator
  • ALPS 100mm faders
  • 4 stereo channels with 2-band EQ and inputs for extra sources
  • Stereo returns & playback
  • All inputs with level control
  • 12 bar meters
  • Mono/stereo function on auxes 1&2
  • Monitor output section
  • Alt stereo output source
  • Configurable USB stereo audio in/out
  • Cakewalk SONAR X1 LE bundled with mixer
  • Rack ears available


USB audio flexibility
Getting audio to and from a computer easily is now a common requirement for live sound and music production. The way this has been implemented on ZED is super-flexible and super-easy! No longer do you need to fiddle around the back of your PC to get to the soundcard inputs, only to find that the levels are all wrong and noisy. Just plug in a USB lead to your ZED, select the USB routing on the mixer and the device on your computer and that’s it! CD quality audio to and from your PC or Mac. Switches and connection through jack socket terminals provide different send/return configurations:-

Send options:
1) Main Mix Left Right (Post-fade)
2) Main Mix Left Right (Pre-Fade)
3) Auxes 1-2
4) Auxes 3-4

Return options:
1) To Stereo 3 channel

MusiQ
ZED-14 features a responsive 3-band, swept mid frequency EQ design which utilises MusiQ – with optimised slope (or Q factor) for equalising individual instruments.

DuoPre™
Based on the proven pre-amps from the hugely successful PA series, ZED-14 has DuoPre pre-amps, which use a two stage design, with carefully controlled amounts of gain in each stage. When amplifying the signal from the XLR input, the gain range is huge - 69dB of range to be exact - and is very evenly distributed around the gain control, meaning better control of signal level. Most of the gain comes from the first stage, so unwanted noise is kept to a minimum. Line level signals are simply plugged into the second stage of the pre-amp by using the line input jack socket, which has the great advantage of less noise when using the line input and also matching to a
higher input impedance.

SONAR X1 LE – Provided Free!
We’ve included Cakewalk SONAR X1 LE with ZED-14 so you can immediately start to use it to create your own music – just add a PC and it couldn’t be easier to get going. You’ll be able to record from your ZED mixer, create tracks and arrange songs, then play back to ZED via the USB port. You can use SONAR X1 LE and your ZED mixer together in many ways – e.g. straightforward recording of a stereo mix, recording tracks individually to build up a song, or using the USB port and software as an effects loop.
Key Features
      • Powered by SONAR X1
      • 32 audio tracks
      • 64 MIDI tracks
      • 8 simultaneous inputs and outputs
      • 24-bit/96 kHz audio quality
      • 24 simultaneous effects
      • 8 simultaneous virtual instruments

스펙

제품사진

동영상

  • 등록된 동영상이 없습니다.

사용자평가

리뷰

질문과 답변

음향기기 > 음향 > 믹서 > 종류 > 아날로그 믹서
6354
ZED 24
음향기기 > 음향 > 믹서 > 종류 > 아날로그 믹서
1281000.0000
KRW
5
5
가격대비 아주 괜찮은 믹서 입니다.
일반저렴한 기타의 믹서보다 우수한 성능과 이큐닝등 아주 만족한 믹서입니다.
착한 가격에 만족하는 믹서 입니다.
5.0
1
