Acoustical operating principle : Pressure gradient transducer

Directional Pattern : Cardioid

Frequency Range : 20 Hz … 20 kHz

Sensitivity at 1 kHz into 1 kohm : 15 mV/Pa ± 1 dB

Rated Impedance : 50 ohms

Rated load impedance ：1 kohms

Equivalent noise level, CCIR 1　：22 dB

Equivalent noise level, A-weighted 2 ：13 dB-A

Maximum SPL for THD 0.5% 3 ：138 dB

Signal-to-noise ratio, CCIR (re. 94 dB SPL) 4　：72 dB

Signal-to-noise ratio, A-weighted (re. 94 dB SPL) 5　：81 dB

Maximum output voltage ：10 dBu

Supply voltage (P48, IEC 61938)：48 V ± 4 V

Current consumption (P48, IEC 61938)：3.2 mA

Matching connector　：XLR 3 F

Weight：approx. 80 g

Diameter：22 mm

Length：107 mm
